Product Introduction:
Thermogravimetry (TG, TGA) is to observe the change of sample quality with temperature or time in the process of heating, constant temperature or cooling, so as to study the thermal stability and components of materials. It is widely used in research and development, process optimization and quality control of plastics, rubber, coatings, drugs, catalysts, inorganic materials, metal materials and composite materials. The following properties of materials were measured and studied: thermal stability, decomposition process, adsorption and desorption, oxidation and reduction, quantitative analysis of components, influence of additives and fillers, water and volatile matter, reaction kinetics.

main features:
1.   the balance is equipped with internal calibration function, which has better accuracy and repeatability.
2.   the imported alloy sensor is more corrosion-resistant, oxidation-resistant and highly sensitive.
3.   the furnace body is heated by precious metal alloy wire winding, which reduces interference and is more resistant to high temperature.
4.   perfect atmosphere control system, automatic switching of software settings, data directly recorded in the database.
5.   with Cortex-M3 core arm controller, the operation processing speed is faster and the temperature control is more accurate.
6.   uses USB two-way communication to fully realize intelligent operation.
7.   use 7-inch 24bit color full-color LCD touch screen to display the status and data of the instrument in real time.
8.   it adopts the top opening structure and is easy to operate. It is very difficult to move the furnace body upward to place the sample, which is easy to cause damage to the sample rod.
9.   Automatically generate test report and print it. The software has built-in test record, data processing and report format, and automatically issues test report

technical parameters:
1. Temperature range: room temperature ~ 1550 ℃
2. Temperature resolution: 0.01 ℃
3. Temperature fluctuation: ± 0.1 ℃
4. Heating rate: 0.1 ~ 100 ℃ / min 5. Temperature control mode: heating and constant temperature
6. Measurement range of balance: 0.01mg ～ 2G
7. Resolution: < span style = "font- size:medium;white-space :normal;">0.01mg
8. Constant temperature time: 0 ~ 300min 9. display mode: Chinese large screen LCD
10. Atmosphere: inert, oxidizing, reducing, static, dynamic
11. Atmosphere device: built in gas flowmeter, including two-way gas switching and flow size control
12. Software: intelligent software can automatically record TG curve for data processing and print experimental report
13. Data interface: standard USB interface, special software (free software upgrade from time to time)
14. Power supply: AC220V     50Hz
